In recent years, the idea of environmental protection industry has promoted the development of adiabatic energy conservation material industry. ASA partition panel has the characteristics of heat insulation, heat preservation, corrosion resistance, high temperature resistance, flame retardant, environmental protection, long service life and other excellent features.
Characteristics
Excellent weather resistance
Wide color/gloss range
Good chemical resistance
Easy co-extrusion
Easy recycling
Eco-friendly
| ASA property parameter table | |||||
| Property item | Test condition | Test method | ASA | Unit | |
| Physical properties | Specific gravity | ASTM D792 | 1.06 | ||
| Water absorption rate | ASTM D570 | 0.03 | % | ||
| Mould contraction rate | 3.2mm | ASTM D955 | 4-6 | E-3 | |
| Melt idex | ASTM D1238 | / | g/10min | ||
| Mechanical properties | Izod notched impact strength | ASTM D256 | 533 | J/m | |
| Tensile strength (yield point) | ASTM D638 | 39 | Mpa | ||
| Tensile rate (rupture point) | ASTM D638 | 30 | % | ||
| Flexural yield strength | ASTM D790 | 54 | Mpa | ||
| Flexural modulus | ASTM D790 | 1650 | Mpa | ||
| Hardness | Rockwell | ASTM D785 | / | R | |
| Thermal properties | Heat deflection temperature HDT/A | 0.45Mpa | ASTM D648 | 96 | °C |
| Heat deflection temperature HDT/A | 1.8Mpa | ASTM D648 | 82 | °C | |
| Vicat softening point | ASTM D1525 | / | °C | ||
| UL Long-term use temperature | UL746B | 50 | °C | ||
| Flame retardant | 3.0mm | UL94 | HB | ||
| Linear Expansibility | fluidity | E831 | / | 1/°C | |
| Electrical properties | Dissipation factor | 60Hz | ASTM D150 | / | |
| Permittivity | 60Hz | ASTM D150 | / | ||
| Dielectric strength | ASTM D149 | / | kv/mm | ||
| (Ohm-cm) Surface residtivity | ASTM D257 | / | Ω-cm | ||
| (Ohm-cm) Volume residtivity | ASTM D257 | 1.00E+15 | Ω-cm | ||
